- Technical specs
| Part number | Variation name | Minimum size in mm | Maximum size in mm |
|---|---|---|---|
| 0041R | Stainless Steel DIN 1.4301 | 3.1 | 4.1 |
| 0045R | Stainless Steel DIN 1.4301 | 3.5 | 4.5 |
| 0305R | Stainless Steel DIN 1.4301 | 3 | 5 |
| 0507R | Stainless Steel DIN 1.4301 | 5 | 7 |
| 0709R | Stainless Steel DIN 1.4301 | 7 | 9 |
| 0911R | Stainless Steel DIN 1.4301 | 9 | 11 |
| 1113R | Stainless Steel DIN 1.4301 | 11 | 13 |
| 1315R | Stainless Steel DIN 1.4301 | 13 | 15 |
| 1517R | Stainless Steel DIN 1.4301 | 15 | 17 |
| 1518R | Stainless Steel DIN 1.4301 | 15 | 18 |
| 1720R | Stainless Steel DIN 1.4301 | 17 | 20 |
| 1922R | Stainless Steel DIN 1.4301 | 19 | 22 |
| 2023R | Stainless Steel DIN 1.4301 | 20 | 23 |
| 2225R | Stainless Steel DIN 1.4301 | 22 | 25 |
| 2327R | Stainless Steel DIN 1.4301 | 23 | 27 |
| 2528R | Stainless Steel DIN 1.4301 | 25 | 28 |
| 2731R | Stainless Steel DIN 1.4301 | 27 | 31 |
| 2831R | Stainless Steel DIN 1.4301 | 28 | 31 |
| 3134R | Stainless Steel DIN 1.4301 | 31 | 34 |
| 3437R | Stainless Steel DIN 1.4301 | 34 | 37 |
| 3740R | Stainless Steel DIN 1.4301 | 37 | 40 |
| 4043R | Stainless Steel DIN 1.4301 | 40 | 43 |
| 4346R | Stainless Steel DIN 1.4301 | 43 | 46 |
| OET0041 | Steel Zinc Plated DIN 1.0338 | 3.1 | 4.1 |
| OET0045 | Steel Zinc Plated DIN 1.0338 | 3.5 | 4.5 |
| OET0305 | Steel Zinc Plated DIN 1.0338 | 3 | 5 |
| OET0507 | Steel Zinc Plated DIN 1.0338 | 5 | 7 |
| OET0709 | Steel Zinc Plated DIN 1.0338 | 7 | 9 |
| OET0811 | Steel Zinc Plated DIN 1.0338 | 8 | 11 |
| OET0911 | Steel Zinc Plated DIN 1.0338 | 9 | 11 |
| OET1113 | Steel Zinc Plated DIN 1.0338 | 11 | 13 |
| OET1315 | Steel Zinc Plated DIN 1.0338 | 13 | 15 |
| OET1517 | Steel Zinc Plated DIN 1.0338 | 15 | 17 |
| OET1518 | Steel Zinc Plated DIN 1.0338 | 15 | 18 |
| OET1619 | Steel Zinc Plated DIN 1.0338 | 16 | 19 |
| OET1720 | Steel Zinc Plated DIN 1.0338 | 17 | 20 |
| OET1922 | Steel Zinc Plated DIN 1.0338 | 19 | 22 |
| OET2023 | Steel Zinc Plated DIN 1.0338 | 20 | 23 |
| OET2225 | Steel Zinc Plated DIN 1.0338 | 22 | 25 |
| OET2327 | Steel Zinc Plated DIN 1.0338 | 23 | 27 |
| OET2528 | Steel Zinc Plated DIN 1.0338 | 25 | 28 |
| OET2731 | Steel Zinc Plated DIN 1.0338 | 27 | 31 |
| OET2831 | Steel Zinc Plated DIN 1.0338 | 28 | 31 |
| OET3134 | Steel Zinc Plated DIN 1.0338 | 31 | 34 |
| OET3437 | Steel Zinc Plated DIN 1.0338 | 34 | 37 |
| OET3740 | Steel Zinc Plated DIN 1.0338 | 37 | 40 |
| OET4043 | Steel Zinc Plated DIN 1.0338 | 40 | 43 |
